Product Detail

Name
AMD Ryzen™ 5 5600GT
Family
Ryzen
Series
Ryzen 5000 Series
Form Factor
Desktops, Boxed Processor
Market Segment
Mainstream Desktop
Regional Availability
Global , China , NA , EMEA , APJ , LATAM
Former Codename
Cezanne
Processor Architecture
Zen 3
# of CPU Cores
6
Multithreading (SMT)
Yes
# of Threads
12
Max. Boost Clock
Up to 4.6 GHz
Base Clock
3.6 GHz
L1 Cache
384 KB
L2 Cache
3 MB
L3 Cache
16 MB
Default TDP
65W
AMD Configurable TDP (cTDP)
45-65W
Processor Technology for CPU Cores
TSMC 7nm FinFET
CPU Compute Die (CCD) Size
180mm²
Package Die Count
1
Unlocked for Overclocking
Yes
CPU Socket
AM4
Thermal Solution (PIB)
AMD Wraith Stealth
Thermal Solution (MPK)
AMD Wraith Stealth
Max. Operating Temperature (Tjmax)
95°C
Launch Date
01/08/2024
*OS Support
Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
Connectivity
PCI Express® Version
PCIe® 3.0
NVMe Support
Boot , RAID0 , RAID1 , RAID10
System Memory Type
DDR4
Memory Channels
2
Max. Memory
128 GB
System Memory Subtype
UDIMM
System Memory Specification
Up to 3200 MT/s
Max Memory Speed
2x1R DDR4-3200
2x2R DDR4-3200
4x1R DDR4-2933
4x2R DDR4-2667
Graphics Capabilities
Graphics Model
Radeon™ Graphics
Graphics Core Count
7
Graphics Frequency
1900 MHz
Product IDs
Product ID Boxed
100-100001488BOX
Product ID Tray
100-000001488
Product ID MPK
100-100001488MPK
